Articulated Narrow Aisle Electric Forklift for Warehouse 2t Load Capacity up to 14m

High quality Warehouse 2ton Up To 14m Articulated Narrow Aisle Electric Forklift

Detailed Photos

Product Parameters

Specification
1	Manufacturer	--	HYDER
2	Model		NA20
3	Capacity	kg	2000
4	Light height	mm	6000/7000/8000/9000/10000/14000
5	Free lift	mm	1965
6	Mast closed height	mm	2865
7	Extended height	mm	7261
8	Overall length	mm	2780
9	Ground clearance	mm	50
10	Overhead guard height	mm	2270
11	Chassis width rear	mm	1220
12	Chassis width front	mm	980
13	Load center	mm	600
14	Wheel base	mm	1735
15	Seat height	mm	1220
16	Mast tilt(back/fwd)	degree	3/1
17	Rotate angle (left/right)	degree	220
18	Ground speed	Km/h	16
19	Lift speed(load/unload)	m/s	0.44/0.5
20	Front tyre size	mm	412*174
21	Rear tyre size	mm	457*150
22	Grade ability(load/unload)	%	18/20
23	Battery voltage/capacity	V/Ah	80V/500AH
24	Weight including battery	kg	7400
25	Weight excluding battery		5800
26	Traction motor	AC	19.5kw
27	Lifting motor	AC	15kw
28	Aisle width	mm	1960
29	Transfer aisle	mm	2700

The head office of HYDER Intelligent Machinery in Yanta district, Xi'an city, our engineer team all have more than 17 years working experience in the fields of forklift. Professional international sale and after sales service team can offer you quick response and effective service. HYDER has built long and stable cooperation with many well-known domestic and oversea enterprises and our products have passed the CE, BV, ISO and third-party detection institution test and certificate. HYDER owns a high efficient team and complete QC system and offers qualified products for the customers in more than 40 countries where the sales network has built.
Shaanxi hyder Intelligent Machinery Co., Ltd. is committed to becoming a high-end intelligent storage and logistics equipment recognized and trusted by the world. We build our national brand with advanced technology, mainly engaged in global warehousing and logistics business.

Our products are Pallet truck series, Stacker series and Electric forklift series. By repeatedly testing in the market and adopting customer feedback, while reducing costs, we are committed to every small function, improving work efficiency, reducing employee operation safety risks, and improving customer use efficiency.
