1300kg Hsls1000 Portable Pallet Stacker Electric Self Loding Stacker
| Place of Origin | China |
|---|---|
| Certification | ISO 9001 |
| Minimum Order Quantity | 1 Set |
| Packaging Details | Sea-Worthy Packing for Exporting |
| Delivery Time | Peak Season Lead Time: 1-3 months Off Season Lead Time: one month |
| Payment Terms | LC, T/T, D/P, PayPal, Western Union |
| Supply Ability | 3000 Sets/Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model NO. | HSLF1300 | Type | Stacker |
|---|---|---|---|
| Power | DC Motor | Load Capacity | ≤1T |
| Fuel | Electric | Load Center | 500mm |
| Lift Height | 800/1000/1300/1600 | Condition | New |
| Name | Electric Self Loading Stacker | Model | Hsls1000 |
| Operating Type | Walkie | Fork With | 550/685mm |
| Transport Package | Sea-Worthy Packing For Exporting | Specification | 2000X1700X800MM |
| Trademark | HYDER | Origin | China |
| HS Code | 84272099 | Supply Ability | 3000 Sets/Year |
| Package Size | 1600.00cm * 800.00cm * 1800.00cm | Package Gross Weight | 350.000kg |
Product Description
Self lifting Stacker is a type of equipment used for handling and stacking goods. It has a self-lifting feature, allowing it to raise goods without the need for external support. This type of equipment is commonly used in warehouses, logistics centers, or manufacturing settings to enhance the efficiency of material handling.
Why do We suggest Full Electric Self lifting Stacker HSLF1000?
>HSLF1000 helps delivery issues by turning a two-person job into one and reducing your workforce needs.
> Reduces employee fatigue, workplace injuries, and employee turnover; improves delivery efficiency. Simply control it's forward and backward by scrolls. Self-propelled machine is more convenient
> Replaces liftgates, ramps, hoists & conventional pallet jacks
> Unlike forklifts, HSLS & HSLF series can go into the delivery truck, protected from the elements
> Battery powered; charges en route or at your facility
> Can be operated by anyone, expanding your potential delivery workforce. The HSLF model is easier for women workers.
| 1 | Standard | |||
| 1.1 | Brand | HYDER FORKLIFT | ||
| 1.2 | Name | 1000kgs full electric self-lift stacker | ||
| 1.3 | Power unit | battery | ||
| 1.4 | Operation | walkie | ||
| 1.5 | Load capality | Q (kg) | 1000 | |
| 1.6 | Load center | C (mm) | 400 | |
| 1.7 | Fork outside spacing | W3 (mm) | 565/685 | |
| 1.8 | Fork length | L2 (mm) | 1295/1195 | |
| 2 | Tire | |||
| 2.1 | Tire type | front/rear | PU/Nylon | |
| 2.2 | Tire no. Driving wheel/Bearing wheel/middle wheel/balanced wheel/ | pcs | 1/4/2/2 | |
| 2.3 | Driving wheel | mm | Φ250×70 | |
| 2.4 | Front wheel | mm | φ80×60 | |
| 2.5 | Middle wheel | mm | Φ65×30 | |
| 2.6 | Universal wheel | mm | Φ40×36 | |
| 3 | Dimension | |||
| 3.1 | Lift height | H (mm) | 800/1000/1300/1600 | |
| 3.2 | Height in Lowerd Position | H1 (mm) | 1166/1366/1666/1966 | |
| 3.3 | Height in highest Position | H2 (mm) | 1850/2250/2850/3450 | |
| 3.4 | Fork height above ground | H3 (mm) | 81 | |
| 3.5 | wheelbase | L0 (mm) | 974 | |
| 3.6 | Total Length | L1 (mm) | 1750/1650 | |
| 3.7 | Middle Wheel Position | L4 (mm) | 172 | |
| 3.8 | Length of Outriggers | L3 (mm) | 771 | |
| 3.9 | Body thickness | L6 (mm) | 409 | |
| 3.10 | Overall Width | W (mm) | 700/780 | |
| 3.11 | Wheel tread Front | W1 (mm) | 400/518 | |
| 3.12 | Width of Fork | B2 (mm) | 193/253 | |
| 3.13 | Thickness of Fork | B1 (mm) | 60 | |
| 3.14 | Min. turning radius | Wa (mm) | 1173 | |
| 4 | Performance | |||
| 4.1 | Max driving speed (Turtle /full load) | km/h | 1.0/3.5 | |
| 4.2 | Gradeability(full load/unload) | % | 5/10 | |
| 5 | Electric Configuration | |||
| 5.1 | Lifting/Descent speed | mm/s | 55/100 | |
| 5.2 | Drive motor/Lift motor | kw | DC0.6/DC1.6 | |
| 5.3 | Battery voltage/capacity | V/Ah | 48/15 Li-ion(20Ah as option) | |
| 6 | Weight | |||
| 6.1 | Battery weight | kg | 5(8 for 20Ah) | |
| 6.2 | Service weight | kg | 340/348/356/365 | |
Hyder is an integrated company of manufacturing, developing and sale all kinds of forklifts and warehouse equipment in China.
Hyder, founded in 2010 in Shanghai and the predecessor is ShanghaiChallengeImported and Exported Co., Ltd in 2003.
The leading products are HYDER Branded series forklift trucks. Shanghai Hyder have invested three manufacturing bases in Anhui and Shandong Province, covering internal combustion counterbalanced forklift trucks, battery powered forklifts, material handling equipments and the related spare parts.
The head office of HYDER Industry in Pudong district,Shanghai city, possessing 23 international market employees,12 logistic support personnel and 12 purchasing staff and technicians. HYDER has built long and stable cooperation with many well-known domestic enterprises and our products have passed the CE,TUV,GS and third-party detection institution test and certificate. HYDER owns a high efficient team and complete QC system and offers qualified products for the customers in more than 30 countries where the sales network has built. Customer is first, Quality is our life.
