Powered Pallet Truck 2t 2.5t Automatic Lifting and Moving 2010X800X1380MM Full Electric
| Place of Origin | China |
|---|---|
| Certification | ISO 9001 |
| Minimum Order Quantity | 1 Set |
| Packaging Details | Sea-Worthy Packing for Exporting |
| Delivery Time | Peak Season Lead Time: 1-3 months Off Season Lead Time: one month |
| Payment Terms | LC, T/T, D/P, PayPal, Western Union |
| Supply Ability | 3000 Sets/Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model NO. | HTE20E | Type | Powered Pallet Truck |
|---|---|---|---|
| Power | AC Motor | Load Capacity | 2.0t-3.0t |
| Fuel | Electric | Load Center | 600 |
| Lift Height | >5000mm | Condition | New |
| Name | 2.5t Standing On Electric Pallet Truck With EPS | Model | Hte20m |
| Drive Motor | AC1.5 | Lift Motor | 2.2kw |
| Battery Voltage/Capacity | 24V/210ah | Contorller | American Curtis |
| Transport Package | Sea-Worthy Packing For Exporting | Specification | 2010X800X1380MM |
| Trademark | HYDER | Origin | China |
| HS Code | 8427109000 | Supply Ability | 3000 |
| Package Size | 180.00cm * 86.00cm * 138.00cm | Package Gross Weight | 500.000kg |
Product Description
138
Automatic lifting and moving full electric pallet truck 2t,2.5t for sale from China forklift factory
Features&Design
1) American Curtis controller;
2) Chinese top quality BAO steel for lifting mast and frame;
3) AC motor and Torch brand big capacity battery;
4) With strong capacity ability;
5) With smaller turning radius
6) Comfortable operations with EPS and seldom breakdown;
7) Lasting working hours:5-6hrs
2) Chinese top quality BAO steel for lifting mast and frame;
3) AC motor and Torch brand big capacity battery;
4) With strong capacity ability;
5) With smaller turning radius
6) Comfortable operations with EPS and seldom breakdown;
7) Lasting working hours:5-6hrs
An electric pallet truck, also known as an electric pallet jack, is a type of material handling equipment used to move pallets and heavy loads within warehouses, distribution centers, and other industrial settings.
When the electric pallet truck is not in use and parked, it will typically be in a standing position, and the key components are as follows:
Forks: These are the horizontal components of the pallet truck that go under the pallet to lift and move it. The forks are usually raised off the ground and leveled to prevent any damage and ensure stability.
Power Unit: The electric pallet truck is powered by an electric motor that drives the wheels. The power unit may be located on the handle or at the base of the truck.
Handle: The handle is where the operator stands and controls the movement of the pallet truck. It often includes the control panel for raising, lowering, and steering the pallet truck.
Wheels: Electric pallet trucks usually have two main sets of wheels: the load wheels at the front under the forks and the drive wheels at the rear, which are powered by the electric motor. Battery: The electric pallet truck is powered by a rechargeable battery, which provides the necessary energy to operate the electric motor.
Safety Features: Modern electric pallet trucks come equipped with safety features such as emergency stop buttons, speed control, and overload protection to ensure safe operation. It's important to note that when an electric pallet truck is not in use, it should be parked in a designated area, preferably on a level surface, with the forks lowered to the ground to prevent accidents and damage to the equipment or surroundings. Additionally, the battery may need periodic recharging to maintain optimal performance.
| NO | Items | Unit | HTE20-Y | HTE25-Y | ||
| 1 | Power type | | Battery | Battery | ||
| 2 | Rated load capcity | kg | 2000 | 2500 | ||
| 3 | Load centre | mm | 600 | 600 | ||
| 4 | Operate type | | Standing on | Standing on | ||
| 5 | Total length(Pedal closed) | mm | 1800 | 1800 | ||
| 6 | Total width | mm | 860 | 860 | ||
| 7 | Min working aisle width 800*1200 pallet | | 205 | 205 | ||
| 8 | Lifting height | mm | 2500 | 2500 | ||
| 9 | Min working aisle width 1000*1200 pallet | mm | 2540 | 2540 | ||
| 10 | Fork Min ground clearance | mm | 85 | 85 | ||
| 11 | Min. Turning radius | mm | 1800 | 1800 | ||
| 12 | Fork side(L*W*H) | mm | 1200*180*55 | 1200*180*55 | ||
| 13 | Fork outer width | mm | 550/680 | 550/680 | ||
| 14 | Type of drive control | / | MOS | MOS | ||
| 15 | Max lifting speed(no load) | mm/s | 100 | 100 | ||
| 16 | Max lifting speed(full load) | mm/s | 50 | 50 | ||
| 17 | Max driving speed(no load) | Km/h | 5.8 | 5.8 | ||
| 18 | Max driving speed(full load) | Km/h | 4.5 | 4.5 | ||
| 19 | Max gradeability(full/no load) | % | 3.0/5.0 | 3.0/5.0 | ||
| 20 | Driving motor | kW | AC1.5 | AC1.5 | ||
| 21 | Lifting motor | kw | 2.2 | 2.2 | ||
| 22 | Total weight | kg | 500 | 500 | ||
| 23 | Battery capacity | V/AH | 12V120AH*2 | 12V120AH*2 | ||
| 24 | Charger | V/A | 24V15A | 24V15A | ||
| 25 | Bearing wheel size(front) | mm | 80*60 | 80*60 | ||
| 26 | Balance wheel size(back) | mm | 125*50 | 125*50 | ||
| 27 | Service Brake | | Electric magnetic | Electric magnetic | ||
| 28 | Steering | | Mechanical | Mechanical | ||
| 29 | Controller | | Chinese brand | Chinese brand | ||
Hyder Forklift is an integrated company of manufacturing, developing and sale all kinds of forklifts and warehouse equipment in China.
Hyder, founded in 2010 in Shanghai and the predecessor is ShanghaiChallengeImported and Exported Co., Ltd in 2003.
The leading products are HYDER Branded series forklift trucks. Shanghai Hyder have invested three manufacturing bases in Anhui and Shandong Province, covering internal combustion counterbalanced forklift trucks, battery powered forklifts, material handling equipments and the related spare parts.
The head office of HYDER Industry in Pudong district,Shanghai city, possessing 23 international market employees,12 logistic support personnel and 12 purchasing staff and technicians. HYDER has built long and stable cooperation with many well-known domestic enterprises and our products have passed the CE,TUV,GS and third-party detection institution test and certificate.
HYDER owns a high efficient team and complete QC system and offers qualified products for the customers in more than 30 countries where the sales network has built. Customer is first, Quality is our life.
HYDER, Your Delivery Effective Resource!
