500kg Capacity Self Lifting Stacker Full Electric High Lifting Height 1.3 Meter Model
| Place of Origin | China |
|---|---|
| Certification | ISO 9001 |
| Minimum Order Quantity | 1 Set |
| Packaging Details | Sea-Worthy Packing for Exporting |
| Delivery Time | Peak Season Lead Time: 1-3 months Off Season Lead Time: one month |
| Payment Terms | LC, T/T, D/P, PayPal, Western Union |
| Supply Ability | 3000 Sets/Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model NO. | HSLF500S | Type | Electric Forklift |
|---|---|---|---|
| Power | AC Motor/DC Motor | Load Capacity | ≤1T |
| Fuel | Electric | Load Center | 400 |
| Lift Height | 800/1000/1300/1600mm | Condition | New |
| Name | 1 Ton Electric Straddle/Walkie Stacker 3m | Model | Hslf1000s |
| Lifting Height | 1600mm | Drive Motor | AC Motor |
| Lift Motor | DC Motor | Transport Package | Sea-Worthy Packing For Exporting |
| Specification | 2110X850X2070MM | Trademark | HYDER |
| Origin | China | HS Code | 84271090 |
| Supply Ability | 3000 Sets/Year | Package Size | 225.00cm * 115.00cm * 235.00cm |
| Package Gross Weight | 720.000kg | Lead Time | 1 Days (1 - 10 Pieces) To Be Negotiated ( > 10 Pieces) |
Product Description
High Lifting Height 1.3 Meter 500kg Capacity Self Lifting Stacker Full Electric
Full electric stacker, commonly known as a forklift, is a powerful and easy to use handling vehicle. It is widely used in factories, warehouses, stations, ports and other places. It can be used to pick up, carry, and stack unit goods, and can complete four compound operations of outbound, handling, loading and unloading, and stacking of finished goods.
| Full-Electric Pallet Stacker HSLF500S | |||||
| Hyder | |||||
| Characteristic | 1.1 | Model | No. | Unit | HSLF500S |
| 1.2 | Motor | Fully electric | |||
| 1.3 | Rated capacity | Q | kg | 500 | |
| 1.4 | Load center | C | mm | 400 | |
| 1.5 | Fork distance | W3 | mm | 685 | |
| 1.6 | Fork length | L2 | mm | 1195 | |
| 1.7 | Operate type | Self Propelled | |||
| Wheels | 2.1 | Wheel(front/ back) | PU Wheels / Nylon wheels | ||
| 2.2 | Drive wheel/ bearing wheel/Middle wheel No. | pcs | 1/2/2 | ||
| 2.3 | Drive wheel size | mm | Φ250×74 | ||
| 2.4 | Bearing wheel size | mm | Φ80×60 | ||
| 2.5 | Middle wheel size | mm | Φ40×30 | ||
| Size | 3.1 | Fork lift height | H | mm | 1000/1300 |
| 3.2 | Total height when fork lowered | H1 | mm | 1300/1600 | |
| 3.3 | Total height fork lifted | H2 | mm | 2271/2871 | |
| 3.4 | Wheel base | L0 | mm | 955 | |
| 3.5 | Truck length | L1 | mm | 1732 | |
| 3.6 | Support leg length | L3 | mm | 747 | |
| 3.7 | Middle Wheel position | L4 | mm | 133 | |
| 3.8 | Safety range | L5 | mm | ≤130 | |
| 3.9 | Total width | W4 | mm | 1449 | |
| 3.11 | Front Wheel distance | W1 | mm | 1320 | |
| 3.12 | Fork width | B | mm | 232.5 | |
| 3.13 | Minimum turning radius | Wa | mm | 1302 | |
| Feature | 4.1 | Max driving wheel(turtle/ full load) | km/h | 0.5/3.0 | |
| 4.2 | Gradeability(full load/ unload) | % | 5/10 | ||
| Electric | 5.1 | Drive motor | kW | DC 0.6 | |
| 5.2 | Lifting motor | kW | DC 1.6 | ||
| 5.3 | Battery voltage | V | 48(Li) | ||
| 5.4 | Battery capacity | Ah | 15 | ||
| Weight | 6.1 | Battery | kg | 5 | |
| 6.2 | Truck(Battery included) | kg | 358/370 | ||
HYDER mainly engaged in global warehousing and logistics business, and has 17+ years experiences forklift.Hyder products are Pallet truck series, Stacker series and Electric forklift series. All of them have passed the CE, BV, ISO and third-party detection institution test and certificate. Hyder professional markting anlysis, sales, QC Systems and after-sales service teams online 24*7, whom providing high effecieny reply and solve customers proble, every forklift will be delivered after qualifying testing, so Hyder offers qualified products for the customers in more than 40 countries where the sales network has built, and get well-known repuation from Hyder servered customers.
Shaanxi hyder Intelligent Machinery Co., Ltd. based on responsible and diligent attitude towards each customer, which mission is becoming a high-end intelligent storage and logistics equipment recognized and trusted by the world.
Q1: Are you a manufacturer or trading company?
A1: We are a manufacturer, and we have our own factory and trading company.
Q2: How is Your Price Compare With Other Factories?
A2: We are professional forklift manufacturers with more than 12 years produce and export experience we can sure to provide
you more competitive price than other factories.
Q3: Can you guarantee your products?
A3: Yes, we guarantee your 100% satisfaction on all our products.
Please feel free to back to us immediately if you are not satisfied with our quality or service. If the product does not meet the contract requirements, we will send you a free replacement or give you compensation in the next order.
Q4: Do you offer custom design?
A4: Custom design is surely available. We have very rich experience in customizing shelves.
Q5: Can you manufacture the forklift as per my requirement?
Yes, these items have other options: lifting height, tires, cabin,lights, fork length, colors,controller, engine, battery, charging voltage. etc.
