Electric Pallet Stacker Forklift Machine 2.0t Load Capacity and for Various Needs
| Place of Origin | China |
|---|---|
| Certification | ISO 9001 |
| Minimum Order Quantity | 1 Set |
| Packaging Details | Sea-Worthy Packing for Exporting |
| Delivery Time | Peak Season Lead Time: 1-3 months Off Season Lead Time: one month |
| Payment Terms | LC, T/T, D/P, PayPal, Western Union |
| Supply Ability | 3000 Sets/Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model NO. | HTB20 | Type | Stacker |
|---|---|---|---|
| Power | AC Motor | Load Capacity | 1T - 5T |
| Fuel | Electric | Load Center | >500mm |
| Condition | New | Name | 2ton Standing-on Electric Stacker |
| Model | Htb20 | Lifting Height | 3000mm--5500mm |
| Drive Motor | AC Motor | Lift Motor | DC Motor |
| Transport Package | Sea-Worthy Packing For Exporting | Specification | 2110X850X2070MM |
| Trademark | HYDER | Origin | China |
| HS Code | 84271090 | Supply Ability | 3000 Sets/Year |
| Package Size | 210.00cm * 90.00cm * 210.00cm | Package Gross Weight | 680.000kg |
Product Description
Cost Effective Electric Pallet Stand on Type 2.0t Electric Pallet Stacker Forklift Machine
1. Load Capacity: Determines the maximum weight the stacker can handle.
2. Lift Height: Indicates the maximum height the forks can reach.
3. Power Source: Can be battery-powered or combustion engine-powered.
4. Fork Length: Determines the size and type of loads the stacker can handle.
5. Fork Width Adjustment: Allows for handling different pallet sizes.
6. Tilt Function: Enables forward and backward tilting of the forks.
7. Controls: User-friendly controls for lifting, lowering, steering, and maneuvering.
8. Safety Features: Emergency stop buttons, alarms, anti-roll-back mechanisms, and operator presence sensors.
9. Maneuverability: Designed for easy navigation in tight spaces.
10. Ergonomics: Features for operator comfort and reduced fatigue.
11. Attachments: Additional tools for handling specific load types or configurations.
12. Safety Lights and Beacons: Enhance visibility and safety in low-light or busy areas.
Hyderlift with over 17 years for producing and exporting , We aim to supply high quality and competitive price to you and to establish a long term service for you . Welcome to contact us for requirements.
*Energy -saving design
*24V electrical system
* Cost-effective deign with AC Motor
*Optimal visibility through the mast
*Fingertip control of all functions
*Direction reverse switch on handle
*Emergency Power disconnect
*Maintenance free battery+ motor
*24V electrical system
* Cost-effective deign with AC Motor
*Optimal visibility through the mast
*Fingertip control of all functions
*Direction reverse switch on handle
*Emergency Power disconnect
*Maintenance free battery+ motor
| Technical Specs | ||||
| NO | Items | Unit | Specs | |
| 1 | Power type | Battery | ||
| 2 | Rated load capcity | kg | 1500 | |
| 3 | Load centre | mm | 500 | |
| 4 | Operate type | Standing on | ||
| 5 | Total length(pedal closed) | mm | 2030 | |
| 6 | Total width | mm | 860 | |
| 7 | Mast closed height | mm | 2080 | |
| 8 | Lifting height | mm | 3000 | |
| 9 | Mast extended height | mm | 3580 | |
| 10 | Min working aisle width 1000*1200mm pallet(1200 along the fork) | mm | 2500 | |
| 11 | Fork Min ground clearance | mm | 85 | |
| 12 | Min. Turning radius | mm | 1612 | |
| 13 | Fork side(L*W*H) | mm | 1100*160*55 | |
| 14 | Fork outer width | mm | 550/680 | |
| 15 | Max lifting speed(no load) | mm/s | 100 | |
| 16 | Max lifting speed(full load) | mm/s | 50 | |
| 17 | Max driving speed(no load) | Km/h | 5.5 | |
| 18 | Max driving speed(full load) | Km/h | 4.5 | |
| 19 | Max gradeability(full/no load) | % | 3.0/5.0 | |
| 20 | Driving motor | KW | DC0.75 | |
| 21 | Lifting motor | kw | DC2.2 | |
| 22 | Total weight (battery included) | kg | 680 | |
| 23 | Battery capacity | V/AH | 24V120AH | |
| 24 | Charger | V/A | 24V15A | |
| 25 | Steel type | Manganese C-shaped steel | ||
| 26 | Bearing wheel size(front ) | mm | 80*70 | |
| 27 | Balance wheel size(back) | mm | 125*50 | |
| 28 | Controller | Chinese brand | ||
| 29 | Service Brake | Electric magnetic | ||
*Energy -saving design
*24V electrical system for different use
* Cost-effective deign with AC Motor
*EPS function optional
*Fingertip control of all functions
*Direction reverse switch on handle
*Emergency Power disconnect
* Complete steel cover and side guards
*24V electrical system for different use
* Cost-effective deign with AC Motor
*EPS function optional
*Fingertip control of all functions
*Direction reverse switch on handle
*Emergency Power disconnect
* Complete steel cover and side guards
* Max load capacity: 1000/1500kg
* Max lifting height 3M
* Lead acid battery 24V 80AH
* Working hours: 5-6hours
* Work for single deck pallets
* Small turning radius
*Energy -saving design
*24V/48V electrical system
*High-strengthen cover
*Rema handle bar
*Fingertip control of all functions
*Direction reverse switch on handle
*Emergency Power disconnect
*Maintenance free battery
The head office of HYDER Intelligent Machinery in Yanta district, Xi'an city, our engineer team all have more than 17 years working experience in the fields of forklift. Professional international sale and after sales service team can offer you quick response and effective service. HYDER has built long and stable cooperation with many well-known domestic and oversea enterprises and our products have passed the CE, BV, ISO and third-party detection institution test and certificate. HYDER owns a high efficient team and complete QC system and offers qualified products for the customers in more than 40 countries where the sales network has built.
Shaanxi hyder Intelligent Machinery Co., Ltd. is committed to becoming a high-end intelligent storage and logistics equipment recognized and trusted by the world. We build our national brand with advanced technology, mainly engaged in global warehousing and logistics business.
Our products are Pallet truck series, Stacker series and Electric forklift series. By repeatedly testing in the market and adopting customer feedback, while reducing costs, we are committed to every small function, improving work efficiency, reducing employee operation safety risks, and improving customer use efficiency.
Q1: Are you a manufacturer or trading company?
A1: We are a manufacturer, and we have our own factory and trading company.
Q2: How is Your Price Compare With Other Factories?
A2: We are professional forklift manufacturers with more than 12 years produce and export experience we can sure to provide
you more competitive price than other factories.
Q3: Can you guarantee your products?
A3: Yes, we guarantee your 100% satisfaction on all our products.
Please feel free to back to us immediately if you are not satisfied with our quality or service. If the product does not meet the contract requirements, we will send you a free replacement or give you compensation in the next order.
Q4: Do you offer custom design?
A4: Custom design is surely available. We have very rich experience in customizing shelves.
Q5: Can you manufacture the forklift as per my requirement?
Yes, these items have other options: lifting height, tires, cabin,lights, fork length, colors,controller, engine, battery, charging voltage.etc
